HTA type hydraulic tubing anchor is a hydraulic setting anchor that can be lowered into a well together with one or more. Especially suitable for large angle inclined or horizontal wells where mechanical and cable sealing is not suitable for entry. Two or more oil pipe anchors can be set at once or set in sequence according to the design order. This packer is widely used in various stimulation measures such as single-layer fracturing, acidification, and layered fracturing.

Features/Advantages

Hydraulic sealing, suitable for high angle wells and horizontal wells

Can be safely sealed within P-110 steel grade casing

The unique ratchet locking ring device will lock tightly and provide long-lasting and effective sealing

Lift and unseal, easy to operate, can adjust the sealing force and unsealing force as needed

The maximum working pressure is 70MPa

Working temperature 177 ℃
