The HTPM packer is an improved high-temperature and high-pressure mechanical packer based on the RTTS packer. Compared with the RTTS packer, it has added a bypass mechanism and greatly improved the rubber cylinder structure. It adopts a three rubber cylinder structure combined with a rubber cylinder shoulder protection structure, which can meet the ultra-high temperature and high pressure environment underground. The HTPM packer can be used for perforation, oil recovery, production enhancement measures, testing, and other operations. The principles of setting and unblocking are consistent with those of the RTTS packer.

Features/Advantages

Alloy toothed mechanical slips and hydraulic anchor claws can be reliably seated in P140 steel grade casing

A reliable three rubber cylinder combination sealing system that can withstand up and down pressure differences during operation

The J-shaped transposition slot can easily achieve sealing and unsealing, and can be sealed multiple times after entering the well

Can withstand up to 105MPa (15000psi)

The maximum applicable temperature is 204 ℃ (400 ℉)
