ESP cable packer is a specialized packer designed specifically for carbon dioxide injection and storage. The packer has two main and auxiliary channels, with the main channel being the carbon dioxide injection channel and the auxiliary channel being the armored cable channel. The lower end of the main channel is connected to an electronic switch valve to control the opening and closing of the channel, while the auxiliary channel cable provides power for the electronic switch valve.

Features/Advantages

Hydraulic setting, control the electronic switch valve to close and then press the setting

Bidirectional slip anchoring ensures the stability of the pipe column during injection process

Cut pin control unsealing, lift the pipe column and cut the pin to lift out the pipe column

Using dedicated high-voltage cable sealing joints to ensure the sealing of cable channels

The main material is made of stainless steel, which is resistant to carbon dioxide corrosion

The maximum working pressure is 25MPa

Conventional rubber cylinders and seals are recommended to be suitable for temperatures below 120 ℃, and can be customized for higher temperatures
